The most effective way of removing colour as well as White/Transparent/Synthetic contaminants including polypropylene from cotton in Blow Room of Spinning Mills.

Salient Features

Independent setting for sensitivity

Separate setting for delay timing

Micro Controlled based individual hardware for individual camera ensures continuous monitoring

Touch screen showing month wise graphic reports

Connectivity to external world

Interlocking facility between blow room machines against any fault like low air pressure

Audio siren and visual indication to call the attention in case of any fault

Any number of profile settings for different cotton can be stored

Capacity: 1000kgs/hr

Touch Screen software and machine micro controllers works as MASTER-SLAVE combination

A unique collection system eliminates turbulence to pick up and transfer all ejected contaminants continuosly to the bag

LNA – Linearised Nozzle Array for better ejection

Multiline

Vetal scan when installed immediately after the Automatic Bale Opener and first cleaner can work for four different assortments of cotton in ABO automatically changing its settings on feedback from machine on cotton change

Flourescent Tube life counter to change when it is due

Specifications

Supply Voltage : 440V AC, 50 Hz.

Power Consumption : Max 1 Kw

Duct Size in mm : 1000 X 100

Machine Size in mm : 1465 X 1000 X 2440

Compressed Air : 6 – 7 bars
