The most effective way of removing COLOR as well as WHITE / TRANSPARENT / PP /SYNTHETIC materials from cotton

Salient features

Wide Scanning Area

More Cameras & More Ejectors

Independent setting for sensitivity

Seperate setting for Delay timing

Micro Controller based individual Hardware for individual camera ensures continuous monitoring

15 inches wide angle color graphics display

Built in computer enhances any type of connectivity to external world

Interlocking facility between blow room machines against any fault like low air pressure

Audio siren and visual indication to call the attention in case of any fault

Online, hour wise, day wise and month wise graphic reports

Any number of profile settings for different cotton can be stored

Capacity 1500 Kgs – 2000 kgs / Hrs.

Independent zoning with line scan cameras focus the contamination directly and activates the nozzles to eject them, results in less good fibre rejection

PC software and Machine Micro controllers works as MASTER – SLAVE Combination

Without PC Machine will work

A unique collection system eliminates turbulance to pickup and transfer all ejected contaminants continuously to the bag

Specifications

Supply Voltage : 440V AC, 50 Hz.

Power Consumption : Max 1 Kw

Duct Size in mm : 1000 X 100

Machine Size in mm : 2065 X 1000 X 2440

Compressed Air : 6 – 7 bars
